Automatic paint tinting machine with 12 stainless steel canisters
for paint colorant
Brief introduction
The dispensing systme is not only precisely controls the dispensing
of ingredients to provide excellent finished paint product
repeatability from batch to batch, but also can serve as a complete
inventory management system.
The system handles everything from formula storage. Since it
dispenses by piston pump, any desired batch size is precisely
dispensed as needed. With software modules included for raw
material (colorants) and finished product inventory. It is the
simple to operate and easy to maintain.
Features
1. Ceramic valve structure, with good corrosion resistance and good
sealing,stable and reliable.
2. The undispensed nozzle will dispense a little colorant in a
specified time to keep the colorant from
drying,which can effectively prevent the nozzle from blocking.
3. Automatic stirring at set time, prevent the colorant inside
canisters from subsidence.
4. Piston pump ensure you precise measurement,free of calibration
life-long.
5. Simple electrical system,easy to maintain.
6. The rolling brush will clean seal ring of nozzle automatically.
7. Adjustable upward speed and dispensing speed of every colorant.
8. Driver software use the same Flink.dat file as
CPS/Hero/Lenteq,and Formula.txt file as TECMEC,it’s
compatible with worldwide major color software.
Technical Data
Application Range: water or oil colorants (1-12 kinds)
Dispensing:Sequential
Maximal Dispensing at one time: 50 ml
Flow Rate:0.25L
Accuracy: 1/384 Y or 0.077 ml
Canister Capacity: (stainless cans)12 canisters in 2.3L
Rated Voltage: 110V/220V±10%
Frequency: 50HZ/60HZ
Rated Power: 150W
Net Weight: 183.5KG
Gross Weight: 217KG
Machine Size:805(L)*710(W)*1230(H) MM
Packing Size: 846(L)*758(W)*1398(H) MM
Sample Show
Packing
Wrap with plastic film first and then in plywood case
Automatic dispenser machine FAQ
1. How many canisters?
12 , 14 , 16 , 24 caniters for option.
2. Can it compatible with worldwide major color software?
-YIJIU software can read Flink.dat file ( which is the formula file
created by CPS / Hero / Lenteq ) and dispense according to the data
of Flink.dat file.
- If your color software create other formula file rather than the
Flink.dat file, you can send to us for checking if we can make our
YIJIU software to read it.
- If you have no color software, you can manage the formula data in
YIJIU software directly.
3. Which the dispensing accuracy?
1 / 384Y or 0.077ml
4. What' the dispensing speed?
0.25L per min
5. What's your after sales service provided?
one year warranty and free spare parts provided
6. What's the packing size for shipping cost?
Gross weight: 217kg , 846(L)*758(W)*1398(H) MM
