5 Gallons Paint Mixing Machine , Fully Automatic Chemical Liquid Mixer

Ask Lasest Price
Brand Name :	YIJIU
Model Number :	YJ-2A-02
Certification :	CE
Supply Ability :	50 SETS PER MONTH

Add to Cart

Product Details
Company Profile

5 Gallons Paint Mixing Machine , Fully Automatic Chemical Liquid Mixer

5 gallons autoamtic paint mixing machine , chemical liquid mixer with fully automatic mixing color

Brief Introduction

The YIJIU automatic gyroscopic mixer YJ-2A-02 is works on the theory that the table revolve around the shaft meanwhile rotate on their axes with the character of high-efficiency , high-speed .

The mixer is specially designed for points of sale color mixing application as well as for semi-industrial applications.

It has been designed to meet the demand of the retail markets with a reduced clamping clearance and for the professional market with a maximum clamping clearance of 400mm.

5 Gallons Paint Mixing Machine , Fully Automatic Chemical Liquid Mixer

Technical Data

Time of Mixing: 15 seconds ~9 mins 45 seconds
Size of Mixing can: 1~20L
Load of Mixing can: 1~35KG
Speed of Mixing can: Adjustable (Default low speed is 100 r/min; default high speed is 150 r/min)
Height of Mixing can: 80~400mm
Power Supply: 220V±10% 50HZ
Rated Power: 750W
Net weight:182KG
Gross weight:233KG
Machine size:800(L)X745(W)X1010(H) MM
Packing size:850(L)X790(W)X1140(H) MM

Application

Chemical liquids : paint colorant , coating , ink , glue , etc.

Features

rotation and revolution go simultaneously during mixing, which solves the problem of uneven and long time mixing caused by single direction rotation. Clamping strength is adjustable, which meets the needs of different size canisters, and also ensure the stability and no deformation force.
The belt is automotive belt imported from Japan, it's durable.The lower plate can be pull out. easy to put the mixing can on or off. There's one clamping motor and one rotating motor in the mixer.
LCD displays in Chinese or English; the failure testing program can judge the fault easily for you. Rotating speed is adjustable to meet the needs of different mixing materials. The data of inverter is automatically set, leaving you no trouble when replace inverter.
It is suitble to big package and high viscosity chemical liquids mixing .
The unique design enables to reduce maintenance to a minimum and therefore allows color mixing to be performed at a low cost per liter colorant.

Mixer machine FAQ

1. Which types of drums can be used for mixer?
Round or Square both OK, but the upper and bottom should be flat.

2.Can it adjust time and speed?
yes,
Time: 15S , 30S , 45S...9mins 45s
Speed: two levels, low speed for big cans and high speed for small cans.

3. What's the max mixing ability?
20L, 35 kg, 5 US gallon

4. Can it be used for other liquid except paint?
yes, any liquid chemicals

Our Service

Inspection: You can send inspectors to our factory for inspection or we self-inspect following the technical requirements mentioned in contracts.

Testing of equipments: all our machines are tested before shipment. All machines are at its optimal state when shipped.

Warranty Service: Warranty period is 12 months. Within guarantee period,we can help you judge the fault according to the failure phenomenon by E-mail. and send replacement part to you except for the man-made factors.

Training:You can send personnel to our factory for free training on the machine.

Brief Introduction

The YIJIU automatic gyroscopic mixer YJ-2A-02 is works on the theory that the table revolve around the shaft meanwhile rotate on their axes with the character of high-efficiency , high-speed .

The mixer is specially designed for points of sale color mixing application as well as for semi-industrial applications.

It has been designed to meet the demand of the retail markets with a reduced clamping clearance and for the professional market with a maximum clamping clearance of 400mm.
